Coil Straightener

Coil Straightener
Coil Straightener
Send Inquiry
Product Code : 001
Product Description



COIL STRAIGHTENER MACHINE

Samay-Asia Special designed coil straightener for coil materials that need high precision punching treatment. As we all know, coil material can’t produce good products without flattening and stress relieving treatment: therefore, the performance of the straightener is critical in the production process.



SPECIAL FEATURES:

  • Multi Straightening Rollers.

  • All rollers are made of D2 steel, have all been quenched, hard chrome plated and grinded with HRC 60°.

  • Achieves perfect leveling performance.

  • Easy to set material thickness.



SPECIFICATION: COIL STRAIGHTENER

Model No:

Coil Width (MM)

Strip Thickness (MM)

Coil O.D.

Motor Power (HP)

S-A/ST-I

S-A/ST -II

S-A/ST -III

S-A/ST –IV

S-A/ST -V

150

200

300

400

500

0.35-1.50

0.35-1.50

0.35-1.50

0.35-1.50

0.35-1.50

2 HP

S-A/ST -VI

S-A/ST -VII

S-A/ST –VIII

S-A/ST –IX

S-A/ST –X

150

200

300

400

500

1.0-3.50

1.0-3.50

1.0-3.50

1.0-3.50

1.0-3.50

3 HP

S-A/ST –XI

S-A/ST –XII

S-A/ST –XIII

200

300

400

1.6-5.0

1.6-5.0

1.6-5.0

5 HP
