Motorised Decoiler Machine

Motorised Decoiler Machine
Send Inquiry
Product Code : 04
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
Product Specifications
  • Type
  • Motorised Decoiler Machine
  • Material
  • Metal
  • Computerized
  • No
  • Drive Type
  • Electric
  • Warranty
  • yes
Product Description

 With a capacity ranging from 5 to 20 tons, Motorised Decoiler Machine is offered by us. It is used for processing application of wire uncoiling at that too at a speed of 18 to 20 m/min. The machine is driven by a powerful motor with loop control. It has the ability to perform up to material width ranging from 50 mm to 1000 m. It performs excellently by consuming less power and do not take much floor space. The Motorised Decoiler Machine has efficient breaking system that enhance its level of performance. It can withstand heavy loads without any wear and tear.

Specifications:

  • Brand: Samay-Asia
  • Material Width: 50 to 1000 mm
  • Model No.: S-A/DE-I
  • Speed: 18 to 20 m/min
  • Capacity: 5 to 20 Tons

Technical Data

Coil Width Max. (mm)

Coil I.D.

Coil O.D.

Coil Weight Max. kg

100

150 - 300

900

150

150

350 - 450

1000

500

250

350 - 450

1200

750

300

400 -500

1200

1000

400

500 - 600

1200

1500

600

550 - 650

1500

2000

1200

550 - 650

1500

3000

1600

550 - 650

1500

5000

Trade Information
  • Payment Terms
  • Cheque
  • Supply Ability
  • 6 Pieces Per Month
  • Delivery Time
  • 8-10 Days
  • Main Domestic Market
  • All India
